4-7 channels, audio mixer, WEB F-7

Professional mixer 4/7 channels Bluetooth/USB/Stereo RCA inputs

Model: F-7
4/7 channel mixer with two stereo channels and one separate stereo channel
Built-in 48V phantom power for condenser microphones.
Integrated effects processor
PAD switch for mono type inputs
"D-PRE" microphone preamplifiers with inverted darlington circuit
XLR balanced outputs
Metal body

Microphone input
Frequency Response: 10Hz - 200kHz
Range Gain: +14dB - +60dB
SNR: 120dB E.I.N

Line input
Frequency Response: 10Hz - 130kHz
Range Gain: -6dB - +38dB
SNR: 95dB EIN
stereo channels
Frequency Response: 10Hz - 70kHz
Range Gain: line -8 +15dB / microphones: +13 - +60dB
SNR: line 90dB EIN / microphone: 104dB EIN

equalization
LOW: 50 Hz, +/- 15dB
MID: 700 Hz, +/- 15dB
HIGH: 10kHz, +/- 15dB
Main mix
Main output: +28dBu balanced / +22dBu unbalanced
AUX: +22dBu unbalanced
EFF: +22dBu unbalanced
Tape out: +22dBu unbalanced
Phone Output: +22dBu unbalanced

Included in the package
power supply
Manual in English
