Imaging sensor

Sensor

1/4 color CMOS

Effective Pixel

1280(H)* 720(V)(1 million pixels)

Lens

f: 3.6mm, F: 2.0

Min. Illumination

0.5Lux

Audio input

Input / Output

Built-in MIV and speaker,Two way Audio Function

Audio Compressing Format

AAC

Video

Video output

1CH HD&SD output

Video standard

HD&SD

Frame Rate

25fps

Video Compressing Format

H.264

Lighting Rate

50Hz,60Hz

Night Vision

12 pcs Infrared light ,IR Distance : 12 m

Back Light Compensation

Auto

Graphic options

Brightness, Contrast, Saturation, sharpness are adjustable

Interface

Power

A DC 5V / 2.0A (optional Europe, American Standard and other standard adapters <7W)

Button

A reset button a 1010FN function buttons

Network Interface

One 10 / 100Mbps adaptive RJ-45 interface

WIFI antenna interface

2 external wireless antenna

Network

Wireless Net

WIFI (IEEE802.11b / g / n),

external wireless antenna

WIFI (IEEE802.11b / g / n), external wireless antenna

IP addresses

static IP address, dynamic IP address

Alarm

Alarm Detection

Motion detect

Alarm Recording

it can take a picture, Audio/video

Other

PTZ Rotation Angle Horizontal

PTZ Rotation Angle Horizontal - 355 ° in orizzontale e verticale 120 °

LED indicate

power / network signal / function indicator

Video Storage

Micro SD card local storage, cloud storage box LAN storage, cloud storage

Specification

Storage Humidity

0% - 90% (non-condensing)

Dimensions (LxWxH)

95 (L) x100 (W) x130mm (H)

Weight

about 500g (including chassis)
